Cooling Units
Cooling Units from Rittal
Rittal offers both roof- and wall-mounted air conditioning cooling units suited for applications requiring cooling outputs ranging from 0.50 to 4.00 kW. The cooling units are available in Stainless Steel, Sheet Steel, and Outdoor options. The outdoor option can withstand temperatures up to 140 °. The Blue e+ series includes revolutionary energy efficiency through innovative hybrid technology that averages a 75% savings on energy efficiency due to speed-regulated components and heat pipe technology.
Unique multi-voltage capability enables worldwide use.
NEW
Blue e+ S from Rittal: The Next Generation of Smart, Powerful Cooling
Rittal’s new Blue e+ S smart cooling units for enclosures offer enhanced cooling outputs and smart capabilities with sustainability in mind. Designed for efficiency, they help to ensure:
- A smaller footprint
- Provide energy savings
- Minimize CO2
Fast and Complete Data Availability
Fast and Reliable Service
Quick and Easy Filter Mat Replacement
Fast and Safe Assembly
Fast and User-Friendly Device Settings
5 Benefits of the Blue e+ Over Traditional Enclosure Cooling Systems
The Blue e+ is a new generation of cooling units that deliver unparalleled energy efficiency with speed-regulated components and patented heat pipe technology. In addition to far higher energy efficiency than existing cooling solutions, the units also offer a range of powerful new features that provide longer component life, flexibility, and ease of use.
The integral heat pipe provides passive climatization, while active climatization is achieved via the compressor’s cooling circuit with speed-controlled components for demand-based cooling. Not only is energy consumption far less than with conventional technology, but the improved cooling leads to a longer service life of the components inside the enclosure and the cooling unit itself.
Watch the Video
Energy Efficiency
- Hybrid technology combines active, compressor-based cooling with a passive-cooling heat pipe.
- Using both active and passive cooling circuits provides greater energy efficiency and decreased electrical use.
Flexibility
- Using inverter technology, Blue e+ air conditioners have multi-voltage capability allowing them to work with virtually any standard voltage including 115V, 230V, or 400/460V.
- The Blue e+ cooling units offer cooling capacities up to 6,000 watts and can be used in environments ranging from -20°C to +60°C.
Longevity
- Thermal management protects sensitive components and extends their service life.
- Blue e+ ensures a more stable, constant temperature compared with traditional cooling systems.
Simplicity
- A secure and accessible USB interface allows for efficient data gathering on temperature, efficiency, diagnostics and more. The touch-screen display provides all relevant information, with system messages appearing as plain text.
- Standardized communication interfaces ensure easy integration in production plant’s control systems.
NFC Capabilities
- IoT-enabled climate control knows current and expected temperatures, adjusting fans and cooling accordingly.
- Blue e+ modules and adapters enable data from cooling units to be used in IoT environments providing centralized management, custom alerts, and better integration.
Wall-mounted Cooling Units
For external mounting or internal mounting in doors and walls using standardised mounting cut-outs. Integral electric condensate evaporation (from 0.3 kW). Cooling output 0.3 kW – 5.8 kW. From 0.3 kW, also available in energy-efficient Blue e+ technology. Protection categories: IP54 / IP55 / IP56, UL Type 3R/4, 12 and NEMA 4X. Wall-mounted cooling units also available in chemical and outdoor versions.
Blue e+ S NEW
0.3 kW – 1 kW
Blue e+ S cooling units with tried-and-tested Blue e+ technology are the world’s most energy-efficient cooling units. This means they reduce the carbon footprint of your machines and systems. Available in a brand new design with a host of smart functions.
Blue e+
1.6 kW – 5.8 kW
Energy-efficient Blue e+ wall-mounted cooling units in output categories 1600 W to 5800 W. Average energy savings of 75% can be achieved with speed-regulated components and heat pipe technology. Available in sheet steel and stainless steel versions.
Blue e+ Outdoor
1.5 kW – 5 kW
Energy-efficient Blue e+ outdoor wall-mounted cooling units in output categories ranging from 1500 W to 5000 W. With their high protection category of IP 56 / UL type 12/3R/4 and a temperature range of -30 °C to 60 °C.
Blue e+ Chemical
1.6 kW – 5.8 kW
Energy-efficient Blue e+ wall-mounted chemical industry cooling units in output classes ranging from 1600 W to 5800 W. Thanks to a special surface finish, these units provide components with optimum protection in contaminated environments.
Blue e+ IT
The use of Blue e+ technology makes this bundle ideally suited to the requirements of energy-efficient cooling of IT racks. In combination with the IoT interfaces, it supports communication with various systems as well as monitoring and energy management.
TopTherm Blue e
0.3 kW – 0.4 kW
Energy-efficient Blue e wall-mounted cooling units in the output categories 300 W to 4000 W and with integral electrical condensate evaporator (from 1000 W). Available in the special formats “horizontal” and “flat”.
TopTherm Blue e, UL Type 3R/4
0.5 kW – 2.5 kW
Energy-efficient Blue e wall-mounted cooling units in output categories 500 W to 2,500 W with integral e-Comfort controller and electric condensate evaporation (from 1000 W) as standard, protection category UL Type 3R/4, 12.
TopTherm Blue e, NEMA 4X
0.5 kW – 2.5 kW
Energy-efficient Blue e wall-mounted cooling units in power categories 500 W to 2,500 W with e-Comfort controller integrated as standard and electrical condensate evaporation. Protection category NEMA 4X.
Need Assistance Sizing for your System?
Our team of expert engineers can help with your application
Roof-mounted Cooling Units
Doors, side panels and escape routes are kept clear thanks to the roof-mounted design. Electric condensate evaporation. Cooling output 0.55 kW – 4 kW. Output category 1.3 kW, also available in energy-efficient Blue e+ technology.
Blue e+
Total Cooling Output: 1.3 kW
Blue e+ S cooling units with tried-and-tested Blue e+ technology are the world’s most energy-efficient cooling units. This means they reduce the carbon footprint of your machines and systems. Available in a brand new design with a host of smart functions.
TopTherm Blue e
Total Cooling Output: 0.5 kW – 4.0 kW
Energy-efficient Blue e roof-mounted cooling units in output categories from 500 W to 4,000 W with e-Comfort controller integrated as standard and electrical condensate evaporation.
Blue e+ IT
The use of Blue e+ technology makes this bundle ideally suited to the requirements of energy-efficient cooling of IT racks. In combination with the IoT interfaces, it supports communication with various systems as well as monitoring and energy management.
